AS9102 Rev C First Article Inspection template & guide
An AS9102 FAIR, or First Article Inspection Report, certifies that each sample was produced and inspected according to the customer's specifications. AS9102 First Articles used by the aerospace and defense industries include 3 forms: Part Number Accountability, Product Accountability, and Characteristic Accountability.
CLOSE
What’s Included:
- AS9102 Rev C Template as an Excel workbook with forms 1, 2, and 3.
- Separate annotated guide with an explanation of every field in the AS9102 Template forms 1, 2, and 3.
What are the three forms of an AS9102 FAIR?
There are 3 forms in AS9102 FAIRs - Part Number Accountability, Product Accountability, and Characteristic Accountability.
AS9102 Form 1: Part Number Accountability
Identify the part for the First Article Inspection (FAI) and associated sub-assemblies or detailed parts.
AS9102 Form 2: Product Accountability
All material and process specifications, as well as any special processes and functional testing defined as design requirements, must be accounted for on Form 2.
AS9102 Form 3: Characteristic Accountability
All product characteristics such as dimensions, tolerances, notes, etc. must be accounted for on Form 3. An inspection drawing or model is required whereby all inspection characteristics (defined using CAD annotations) are clearly identified with uniquely numbered inspection balloons. The numbers on the inspection balloons must correspond to the characteristic numbers on Form 3.
When should I conduct a First Article Inspection?
A First Article Inspection is typically called for in a purchase order contract between the producer and buyer.
The most common reason to conduct a FAI is that it's required by your customer. According to SAE, here are the times a First Article is required:
- The first production run of a new product
- Design change
- Materials or sources change
- It has been more than 2 years since the part was produced
- Change in process, tools, or location
